APPLE A14 DIESHOT

Image from techinsights,floor plan by me.

A14 are basically a upgrade of A13,made by the same stuff with M1.It have the Same Firestorm core with M1 and same L2 size with A13. GPU are same with A13,and IP block are same with A13 but replaced.Same 16-core Neural Engine and Icestorm cluster with M1.

A14area(mm^2)size(MiB)SRAM density(MB/mm^2)
Firestorm L22.38591549383.353010626
Icestorm L21.19311530243.352567848
SLC4.359688836163.669986689
TSMC 5nm HP3.579030795123.35286302
TSMC 5nm HD4.359688836163.669986689
total7.938719631283.527017114
M1(TSMC 5nm HD)M1(TSMC 5nm HP)A14(TSMC 5nm HD)A14(TSMC 5nm HP)Lakefield(Intel 10nmSF)SD855(TSMC 7nm DUV)K980(TSMC 7nm DUV HD)KX5000(HLMC 28nm)
SRAM density3.4280433483.2537395073.6699866893.352863021.6759875652.4638929742.3866525520.407069712
Relative upshift0.00%5.36%-6.59%2.24%104.54%39.13%43.63%742.13%

Cuz there are not any accuracte data of M1/A14’s Diesize,so data are not totally accuracte.

xian333c

tech nerd,Vup
